iRay Bolt TD50L Features
-
Features onboard recording capabilities for both video and images.
-
Has an impressive operational temperature range of -4°F to 122°F with an ingress protection of IP67.
-
The device can be mounted using 30MM rings which are included in the package.
-
Made with robust T-6061 Aluminum, the device is durable and weighs 35.27 Oz.
-
It has a high-resolution CMOS sensor with a frame rate of 50Hz.
-
The device offers manual focus and a detection range of up to 600 yards.
-
Comes with a 5-year warranty and has a startup time of under 10 seconds.
-
The device has a storage capacity of 16GB and offers user-updatable firmware.
-
Features a mobile app and has a run time of 10 hours powered by a Li-Ion Battery Pack.
-
The iRay Bolt TD50L includes features like One-Shot Zero, Stand-by Mode, and six reticle options.
-
Can be powered by an external source and comes with a USB-C connector type.
iRay Bolt TD50L Specifications
- Wifi: Yes
- Onboard Recording: Video and Image
- Image Capture: Yes
- Operating Temperature Range: -4°F to 122°F
- Recoil Rating: 1000 g/s² (300 Win./7mm Mag)
- Ingress Protection: IP67
- Mounting Interface: 30MM Rings (included)
- Housing Material: T-6061 Aluminum
- Weight: 35.27 Oz
- Height: 2.95
- Width: 3.34
- Length: 15.55
- Device Technology: Digital Night Vision
- Sensor Type: CMOS
- Sensor Pixel Size: 4µm
- Sensor Frame Rate: 50Hz
- Sensor Resolution: 1440×1080
- Objective Focal Length: 50mm f/1.2
- Display Type: LCOS
- Eye Relief: 70mm
- Digital Magnification: 4X
- Diopter Range: -4 – +4
- Vertical Angular Field of View: 4.9°
- Horizontal Angular Field of View: 6.6°
- Focusing Mechanism: Manual Focus
- Objective F#: 1.2
- Objective Diameter: 50mm
- Objective Lens Material: Glass
- Display Resolution: 1280×960
- Detection Range: 600 Yards
- Optical Magnification: 4X
- Warranty:Â 5 Years
- Startup Time: Under 10 Seconds
- Rangefinder: Stadiametric
- Picture-in-Picture: Yes
- Storage Capacity: 16GB
- User-Updatable Firmware: Yes
- Mobile App: Yes
- Run Time: 10
- Power Source: Li-Ion Battery Pack
- One-Shot Zero: Yes
- Stand-by Mode: Yes
- Reticle: 6
- Connector Type: USB-C
- External Power Source: 18500/18650
What's in the box of the iRay Bolt TD50L?
- iRay Bolt TD50L Digital Night Vision Scope
- Objective Lens Cap
- Eyeshade
- 30mm Ring Mounts for Picatinny Rail
- Soft Case
- USB-C Data/Charging Cable
- Wall adapter
- Lens cloth
- User manual
iRay Bolt TD50L FAQs
- What type of sensor does the iRay TD50L use?- The iRay TD50L uses an ultra-sensitive 1440×1080 CMOS sensor.
- What is the detection range of the iRay TD50L?- The iRay TD50L offers a detection range of up to 600 yards.
- What is the power source for the iRay Tube TD50L?- The device is powered by a Li-Ion Battery Pack. It also accepts an external power source of 18500/18650.
- Does the iRay Tube TD50L have a mobile app?- Yes, the iRay Bolt TD50L is compatible with a mobile app for a more streamlined user experience.
- What is the operation temperature range for the InfiRay Bolt TD50L?- The device can operate within a temperature range of -4°F to 122°F.
- How long is the warranty for the iRay Bolt TD50L?- The iRay Bolt TD50L comes with a 5-year warranty.
- How much onboard storage does the InfiRay Bolt TD50L offer?- The iRay Bolt TD50L offers an onboard storage capacity of 16GB.
- What is the weight of the iRay Bolt TD50L?- The iRay Bolt TD50L weighs 35.27 Oz.
